Important One Liner Question With Answers, Part 5

-


I am presenting here most important (mixed topic) one liner questions with their answer from civil engineering, in which most are asked in various competitive examinations. Please go through it.

Image Source:-Pexels.com

     (1.)  Francis, Keplan, Propeller tuebines is an example of- Reaction Turbine

     (2.)  Normal range of diversion cone of a venturimeter-7 to 15

     (3.)  The runoff increases with-increases in intensity of rain

     (4.)  The steel used for manufacturing rails is-Bessemer steel

     (5.)  The imaginary line joining the points of equal R.L. on the earth surface is-Contour Line

     (6.)  Density index is term used in relation to-Coarsed grained soil or sand
Image Source:-Pexels.com

     (7.)  The minimum reading that can be taken with prismatic compass is-15’

     (8.)  Quantity of brick wall is measured in squ mtr if the thickness of wall is-10 cm

     (9.)  Material used for making of metallic tape is-Cloth and wire

    (10.) Closed contours of minimum value at center represents-Depression

 Also Read:-Important One Liner Question With Answer, Part 1

    (11.)Turnout per mason per day fabric work in mud mortar in foundation and plinth is-1.50 cum

    (12.) Chain surveying is preferred for-Small areas in open ground

    (13.) A line drawn by joining various points having equal amount of rainfall in a given period is called-Isohyet
Image Source:-Pexels.com

    (14.) For rough or hilly ground, what is the permissible limits of error in chaining-1:250

    (15.)Irrigation engineering mainly deals with supplying water for-Nourishment of Crops

    (16.) Mean annual precipitation in terms of depths, received is about-1.2 m

    (17.) High specific speed of a pump means it is-Axial flow pump

    (18.)Working principle of an optical square is-Double reflection

Image Source:-Pexels.com

    (19.) What is the height of bottom of sink of wash basin from the floor level-75 cm to 80 cm

    (20.) Sand stone has a compressive strength of-55 MN/m2

  Also Read:Important One Liner Question With Answers, Part 2

    (21.) Stoke’s law valid for particles diameter ranging from-0.2 to 0.0002 mm

    (22.) Effective storage for a flood control reservoir is- useful storage+ Surcharge storage- Valley storage


    (23.) Flow separation is likely to take place when the pressure gradient in the direction of flow is-Adverse

    (24.) Positive displacement of slurry pumps are the type of- Diaphragm pump

    (25.) The continuity equation is the result of application of the following law to the flow field-Conservation of mass

    (26.)If a domestic sewer pipe laid at a gradient 1 in 100, what is the preferred diameter of sewer pipe-150 mm

Image Source:-Pexels.com

    (27.) A level line is defined as-line parallel to mean spheroidal surface of earth

    (28.) The corner or external angle on the face side of wall is called as-Beveled edge

    (29.) In designing a staircase the product of tread in cm and the rise in cm should be-400

    (30.) In case of Newtonian fluid for laminar flow, what is the ratio of average fluid velocity to the maximum velocity-0.5

Image Source:-Pexels.com
    Also Read:Important One Liner Question With Answer,Part-3


    (31.)Pycnometer method is suitable for only-Coarse grained soil

    (32.)Fluid is a substance, which does not change its-Shape

    (33.)The vertical member which supports the door frame are called-Jambs

    (34.) Piles are usually not made of-Stainless Steel

    (35.) Hydrometer is usually calibrated at a temperature-270C

    (36.) Density index value for loose soil is-Greater than 65 %

    (37.) To remove extra water from an irrigation channel into natural drain, canal structure used is-Canal escape

Image Source:-Pexels.com

    (38.) Percentage of water content in soil can-take values only from 0 % to 100 %

    (39.) Chief ingredient of a paint is-Pigment

    (40.) The volume of cement in 50 kg bag is-35 cu cm

    (41.) The unit measurement quintal is for-Expanded metal wire netting

    (42.) Minimum width of septic tank is considered as-75 cm

    (43.)Assumption in Bligh’s theory of seepage is-equal weightage to the horizontal and vertical creep

    (44.) The water in excess of the moisture that can be retained by the soil called as-Gravitational Water

    (45.)Single grained structure is characteristics of coarse grained soil with a particle size-greater than 0.02 mm


    (46.)Sedimentation analysis is based on-Stoke’s Law

    (47.)For Newtonian fluid, stress-strain relationship is-Linear

    (48.) A plane tangential to the level surface at a particular point is-Horizontal Plane

    (49.)The liquid limit and plastic limit is considered for-Clay Soils

    (50.)Marl soil Contains clay content-Not more than 75 %

    (51.) Which option is the classification based on function of canal-Navigation Canal



Image Source:-Pexels.com
